Mainboard |
|
| Hãng sản xuất | ASUS |
| Model | Pro WS W680M-ACE SE |
| Chipset | W680 |
| Socket | LGA1700 |
| Kích thước | micro-ATX Form Factor 9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm ) |
| Bộ nhớ ram | 4 x DIMM, Max. 192GB, DDR5 |
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS(text-based) |
| Cổng xuất hình | x DisplayPort** 1 x HDMI® port*** 1 x VGA port from AST2600 |
| Khe cắm | - 1 x PCIe 5.0 x16 slot, - 1 x PCIe 4.0 x4 slot - 1 x PCIe 3.0 x1 slot |
| Lan | 2 x Intel® 2.5Gb Ethernet 1 x Realtek 1Gb Ethernet dedicated for AST2600 ASUS LANGuard |
| Âm thanh | Realtek 7.1 Surround Sound High Definition Audio CODEC |
| Card đồ họa | Supports max. 8K@60Hz as specified in DisplayPort 1.4. ***Supports 4K@60Hz as specified in HDMI 2.1 |
| Phần mềm và UEFI | ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUSTek. EzFlash Utility |
| Hệ điều hành | Windows® 11, Windows® 10 64-bit |
| Phụ kiện | Cables 2 x SATA 6Gb/s cables Miscellaneous 1 x Q-connector 1 x M.2 Rubber Packages 2 x Screw package for M.2 SSD 1 x I/O Shield Documentation 1 x User guide 1 x ACC Express Activation Key Card |
